JUDE Ultrasonic Sound Transducer

Frequency:500 Hz to 15MHz
Transmit voltage response:up to 180dB µPa/V@1m
Bandwidth:Low Q(<2 underwater) and Broadband
Depth:up to 5000m
Beam Angle(-3dB):0.8° to Omnidirection
Product Description:
1.High Power Tonpilz Broadband Transducer
Frequency:1.5 to 150KHz
Transmit voltage response:up to 145dB µPa/V@1m
Bandwidth:Low Q(<2 underwater) and Broadband
Depth:up to 5000m
Receiving Sensitivity:up to -170dB V/µPa

2.High Power Sandwich Broadband Transducer
Frequency:50 to 1500KHz
Transmit voltage response:up to 165dB µPa/V@1m
Receiving Sensitivity:up to -190dB V/µPa
Bandwidth:Low Q(<2 underwater) and Broadband
Depth:up to 5000m

3.Omnidirectional and Hemispherical Transducer
Resonant Frequency:20 to 250KHz
Transmit voltage response:up to 145dB µPa/V@1m
Receiving Sensitivity:up to -180dB V/µPa
Bandwidth:Low Q(<2 underwater) and Broadband
Depth:up to 300m
Size:SØ170-SØ8mm

Certification:

Factory:

Shipping:

Most our products delivery to customer by air via express company, like DHL,UPS,TNT ,EMS etc.
Transport time : one week can arrival customer office after send out from us .

We have enough foam inner packing and skin packing .
