Ultrasonic cleaning transducer
Brand name: | JUDE |
Model No: | JD5938D-28H |
Material: | PZT |
MOQ: | Negotiable |
Payment: | T/T, L/C |
Order Delivery Time: | Within 30 working days |
Transportation: | By air via express company, like DHL, TNT, UPS, EMS |
Ultrasonic cleaning machine including vehicles, ships, aircraft surface cleaning, only remove the relatively large dirt; precision industrial ultrasonic cleaning machine cleaning including a variety of products in the production process of cleaning, cleaning of various materials and equipment surface Washing, etc., to be able to remove small dirt particles for the characteristics of ultra-precision ultrasonic cleaning machine.Super precision ultrasonic cleaning machines includes precision industrial production processes for mechanical parts, electronic components, and optical components, ultra-precision cleaning to remove tiny dirt particles for the purpose.
Feature:High quality
High sensitivity
Models and Techanical Data:
Type | Radial Frequency fr(KHz) | Resonance impedance Rt(%) | capacity C(pf) | Power output w |
JD4535D-28H | 28 | 15 | 4000 | 50 |
JD4535D-40H | 40 | 15 | 4000 | 50 |
JD5938D-28H | 28 | 12 | 5000 | 60 |
JD3938D-40H | 40 | 8 | 5000 | 50 |
JD6745D-25H | 25 | 15 | 6500 | 100 |
JD6345D-28H | 28 | 15 | 6500 | 100 |
JD6550D-28H | 28 | 15 | 7000 | 120 |
Size：
JD5938L-28H | JD | Our company code |
59 | Diameter of radiating surface | |
38 | Diameter of PZT | |
L | Two pieces PZT crystal | |
28 | Resonance frequency | |
H | trumpet-shape radiating surface |
*All products can be customized according to customer requirements.
Weifang Jude Electronic Co.,Ltd is a manufacturer of piezoelectric ceramic components, we have been engaged in this industry for 20 years, we have our own factory, experienced technical staff, we achieves the ISO 9001 Certification.
We cooperate with the domestic first-class universities, establish a professional piezoelectric ceramic R&D room, with all this support, we can provide the best product quality and best service.
Research and Development Institute:www.xjtcyjy.com
Certification:
Factory:
Shipping:
Most our products delivery to customer by air via express company, like DHL,UPS,TNT ,EMS etc.
Transport time : one week can arrival customer office after send out from us .
We have enough foam inner packing and skin packing .
Contact:
E-mail: sales@pztceramics.com
WhatsApp:+86 13165361320
Skype:Violet Shan
Tel/Fax: 86-0536-2221236
Website: www.pztceramics.com
