Piezoelectric ceramic sensor-(JD3934A-402S/JD3934A-403S)

Our piezo sensor JD3934A-402S/JD3934A-403Ssize as following:
Disc: outside diameter 34mm,inner diameter 14mm, thickness 6mm
whole body:diameter 39mm, thickness or height 21mm
transmitting wire length  25cm or according your requirements.
Packing:50 pair/carton 36x28x18cm G.W:15.5kgs
Availability:
Inquire Add to Basket

Specification and technical datas as following:


Model  Resonance frequency
 khz±10%		 Resonance impendance
 Capacity
pf±10%		 Measurement
precision
JD3934A-402S 40 350 2400 <3g
JD3934A-403S 42 400 2400 <3g

1.Application:applied in product kinds of tire balancers
2.Features:good stability,good consistency,and accurate measuring
3.We can supply big quantity,usual 20000pairs/moth
4.Piezoelectric Material:PZT-5

Our piezo sensor JD3934A-402S/JD3934A-403Ssize as following:
Disc: outside diameter 34mm,inner diameter 14mm, thickness 6mm
whole body:diameter 39mm, thickness or height 21mm
transmitting wire length  25cm or according your requirements.
Packing:50 pair/carton   36x28x18cm  G.W:15.5kgs




Application:

application


Certifications:

cert

Factory:

factory

Shipping:

Most our products delivery to customer by air via express company, like DHL,UPS,TNT ,EMS ETC.
Transport time : one week can arrival customer office after send out from us .
We have enough foam inner packing and skin packing .

shipping
