1. High Power Tonpilz Broadband Transducer
Frequency: 1.5 to 150kHz
Transmit Voltage Response: up to 145 dB µPa/V@1m
Receiving Sensitivity: up to -170 dB V/µPa
Bandwidth: Low Q (< 2 underwater) and Broadband
Depth: up to 5000 m
2. High Power Sandwich Broadband Transducer Frequency: 50 to 1500kHz
Transmit Voltage Response: up to 165 dB µPa/V@1m
Receiving Sensitivity: up to -190 dB V/µPa
Bandwidth: Low Q (< 2 underwater) and Broadband
Depth: up to 5000 m
3.Omnidirectional and Hemispherical Transducer
Resonant Frequency: 20 to 250kHz
Transmit Voltage Response: up to 145 dB µPa/V@1m
Receiving Sensitivity: up to -180 dB V/µPa
Depth: up to 300 m
Size: SØ170- SØ8 mm
Shipping:
Most our product like piezoelectric sound transducer delivery to our customer by air via express company, like DHL, UPS, TNT, EMS ETC.
Transport time:one week can arrival customer officer after send out sound transducer from us.
We have enough foam inner packing and skin packing.
