Curved piezoelectric composite material transducer for marine technology

Curved Piezoelectric composite material transducer  (2#2.5×2.5×4.35mm

Brand name: JUDE
Model No: Piezoelectric composite material transducer
Material: PZT
MOQ: Negotiable
Payment: T/T, L/C
Order Delivery Time: Within 30 working days
Transportation: By air via express company, like DHL, TNT, UPS, EMS

Feature: High electric coupling constant
               Low agent wear
               Small mechanical quality constant
               Low acoustic impedance
Specification:

Number Resonant frequency Resonance point conductance 300kHz
conductance
Static capacitance
kHz mS mS nF
2#curved piezoelectric composite material transducer 355 95 15 14.2


Directivity(@300kHz):
图片14图片15

                          Horizontal directivity 2θ-3dB=40°                                            Vertical directivity
Transmitting Voltage Response:
QQ截图20160926155127

                  Center frequency 390KHz maximum transmit voltage response 165dB bandwidth50KHz
 *All products can be customized according to customer requirements.
 Application: Fish finder sonar
                      Collision avoidance sonar
                      3D image sonar
                      Side scan sonar
We specialize in piezoelectric ceramics and sensors for 20 years, with good quality and competitive price. The company achieves the ISO9001 Certification.

cert
factory
shipping
